Descriere
Temporizatorul mecanic Mureva Styl MUR35067 este un dispozitiv robust si convenabil. Permite intarzieri de la 2 la 14 minute. indicele sau de protectie IP55 ii asigura impermeabilitatea si permite instalarea in interior si exterior. Dimensiunile sale sunt: 80mm inaltime, 76mm latime si 76mm lungime
Documente
Specificatii
| Material | |
| Surface protection | Untreated |
| Surface finishing | Matt |
| Material | Plastic |
| Halogen free | Yes |
| Material quality | Thermoplastic |
| Model/type | |
| Model | Mechanical |
| Number of modules (module system) | 1 |
| With semiconductor output | No |
| Assembly arrangement | Basic element with complete housing |
| Protection | |
| Suitable for degree of protection (IP) | IP55 |
| Colour | |
| RAL-number (similar) | 7016 |
| Transparent | No |
| Colour | Grey |
| Options | |
| IFTTT support available | No |
| Measurements | |
| Min. depth of built-in installation box | - |
| Electrical | |
| Rated current | 10 A |
| Nominal voltage | 230 V |
| Setting/control | |
| Time setting | 2 min |
| Mounting/installation | |
| Mounting method | Surface mounted |
| Connection | |
| Number of contacts as normally open contact | 1 |
| Number of contacts as change-over contact | 1 |
| Number of contacts as normally closed contact | 1 |
| Communication | |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Package 1 | |
| volume | 462,08 cm3 |
| weight | 211 g |
| length | 7,6 cm |
| width | 8 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606480789496 |
| Package 2 | |
| volume | 36000 cm3 |
| weight | 8,081 kg |
| length | 40 cm |
| width | 30 cm |
| qmax | 36 |
| qmin | 36 |
| um | CT |
| gtin | 43606480789494 |
| Package 3 | |
| volume | 432000 cm3 |
| weight | 63,088 kg |
| length | 120 cm |
| width | 80 cm |
| qmax | 288 |
| qmin | 288 |
| um | PF |
