Auxiliary contact block, TeSys Deca, 2NC, side mounting, lugs-ring terminals
Documente
Specificatii
| Connection | |
| Number of contacts as normally open contact | 0 |
| Number of contacts as change-over contact | 0 |
| Number of contacts as normally closed contact | 2 |
| Type of electric connection | Other |
| Model/type | |
| Model | Clip-on |
| Lamp holder | - |
| Number of fault-signal switches | 0 |
| Electrical | |
| Rated operation current Ie at AC-15, 230 V | 10 A |
| Mounting/installation | |
| Mounting method | Side mounting |
| Package 1 | |
| volume | 184,26 cm3 |
| weight | 60 g |
| length | 8,3 cm |
| width | 7,4 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3389110821369 |
