Descriere
Changeover Contactor, TeSys Deca, 4P(4NO), AC-1, <=440V, 125A, 230V AC 50/60Hz coil, screw clamp terminals
Documente
Specificatii
Connection | |
Type of electrical connection of main circuit | Screw connection |
Number of normally closed contacts as main contact | 0 |
Number of normally open contacts as main contact | 4 |
Type of electrical connection for auxiliary- and control current circuit | Screw connection |
Electrical | |
Rated control supply voltage AC 50 Hz | 230 V |
Rated control supply voltage AC 60 Hz | 230 V |
Rated operation power at AC-3, 400 V | - |
Rated operation power NEMA | - |
Rated operation current Ie at AC-1, 400 V | 125 A |
Rated operation current Ie at AC-3, 400 V | 80 A |
Voltage type for actuating | AC |
Rated control supply voltage DC | - |
Mounting/installation | |
Suitable for rail mounting | No |
Model/type | |
Function | Changeover contactor |
Protection | |
Degree of protection (IP) | IP20 |
Degree of protection (NEMA) | Other |
Package 1 | |
volume | 8624,448 cm3 |
weight | 3,892 kg |
length | 25,2 cm |
width | 18,6 cm |
qmax | 1 |
qmin | 1 |
um | C62 |
gtin | 3389110267129 |
Package 2 | |
volume | 36000 cm3 |
weight | 8,271 kg |
length | 40 cm |
width | 30 cm |
qmax | 2 |
qmin | 2 |
um | CT |
gtin | 43389110267127 |
