Descriere
Modul Buffer - 24 - 28.8 Vcc - 40 A - Pentru Surse De Alimentare
Documente
Specificatii
| Options | |
| Potential free switch contact | FALSE |
| Auto shut down function | FALSE |
| Modular | FALSE |
| SNMP | FALSE |
| Electrical | |
| Input voltage | 24 V |
| Output power factor | - |
| Max. voltage distortion output (linear load) | - |
| Output apparent power | - |
| Number of phases primary | 1 |
| Number of phases secondary | 1 |
| Voltage type | DC |
| Output voltage | 23.5 V |
| Connection | |
| Number of output connections C19 | 0 |
| Number of output connections C13 | 0 |
| Number of output connections with protective contact CEE 7/3 (type F) | 0 |
| USB interface | FALSE |
| Input connection | Other |
| Number of output connections fixed connection | 0 |
| Number of output connections French standard (Type E) | 0 |
| Application | |
| Suitable for network-management | FALSE |
| Performance | |
| Efficiency in eco-mode | - |
| Overall efficiency | - |
| Output effective power | - |
| Communication | |
| With communication interface RS-232 | FALSE |
| Measurements | |
| Height | 146 mm |
| Width | 85 mm |
| Weight | 1.2 kg |
| Depth | 140 mm |
| Other | |
| Primary frequency | - |
| Secondary frequency | - |
| Bridging time full load | 0.1 min |
| USV- technology | Offline |
| Model/type | |
| Construction type | Freestanding model |
| Package 1 | |
| volume | 3558,1 cm3 |
| weight | 1,401 kg |
| length | 18,2 cm |
| width | 17 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3389119406819 |
| Package 2 | |
| volume | 360000 cm3 |
| weight | 97,06 kg |
| length | 80 cm |
| width | 60 cm |
| qmax | 60 |
| qmin | 60 |
| um | PF |
| gtin | 73389119406818 |
