Specificatii
| Measurements | |
| Width | 68 mm |
| Height | 68 mm |
| Diameter openings | 22.5 mm |
| Depth | 53 mm |
| Protection | |
| Degree of protection (IP) | IP66 |
| Degree of protection (NEMA) | Other |
| Colour | |
| Colour housing cover | Grey |
| Model/type | |
| Number of command positions | 1 |
| Construction type housing | Surface mounted housing |
| Material | |
| Housing material quality | Acrylonitrile butadiene styrene (ABS) |
| Housing material | Plastic |
| Package 1 | |
| volume | 367,5 cm3 |
| weight | 114 g |
| length | 7 cm |
| width | 7 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3389110114737 |
| Package 2 | |
| volume | 36000 cm3 |
| weight | 7,391 kg |
| length | 40 cm |
| width | 30 cm |
| qmax | 60 |
| qmin | 60 |
| um | CT |
| gtin | 43389110114735 |
| Package 3 | |
| volume | 360000 cm3 |
| weight | 69,404 kg |
| length | 80 cm |
| width | 60 cm |
| qmax | 480 |
| qmin | 480 |
| um | PF |
