Specificatii
Connection | |
Number of sensor-/actuator-slots | 1 |
Connection for NPN-sensors | No |
Number of poles sensor/actuator slots | 16 |
Thread sleeves sensor/actuator slots | Other |
Connectable conductor cross section | 0.09 mm² |
Electrical | |
Max. current carrying capacity per socket | 1.8 A |
Operating voltage | 24 V |
Max. total current | 1.8 A |
Max. current carrying capacity per I/O signal | 0.5 A |
Rated voltage | 24 V |
Colour | |
Housing colour | Grey |
Material | |
Material of contact surface | Other |
Material contact body | Other copper alloys |
Housing material | Plastic, metallized |
Material insulation body | Other |
Model/type | |
With potential separation | No |
Type of connector for trunk line | - |
With LED indication | Yes |
Type of branches for sensor-/actuator cables | Other |
Measurements | |
Height | 63 mm |
Width | 106 mm |
Diameter contact female | 2.5 mm |
Depth | 64 mm |
Length of the preassembled cable | - |
Cable outer diameter for cable gland | 0.09 mm |
Protection | |
Degree of protection (IP) | IP2X |
Explosion safety category for dust | None |
Explosion safety category for gas | None |
Degree of protection (NEMA) | - |
Other | |
Pollution degree | 2 |
Number of channels per connector slot | 16 |
Options | |
Cable length configurable | Yes |
Application | |
Fix cable version suitable for cable guide chain | No |
Operating conditions | |
Operating temperature | -5 °C |
Package 1 | |
volume | 780,64 cm3 |
weight | 144 g |
length | 13,6 cm |
width | 8,2 cm |
qmax | 1 |
qmin | 1 |
um | C62 |
gtin | 3389110251180 |
Package 2 | |
volume | 36000 cm3 |
weight | 5,05 kg |
length | 40 cm |
width | 30 cm |
qmax | 32 |
qmin | 32 |
um | CT |
gtin | 43389110251188 |
