Acti9, Bare Colectoare Tip Pieptene, 3L, Inclinare 18mm, 57 Module, 100A
Documente
Specificatii
| Measurements | |
| Length | 1000 mm |
| Cross section | 16 mm² |
| Width in number of modular spacings | 57 |
| Module width | 18 mm |
| Colour | |
| Colour | White |
| Options | |
| Insulated | Yes |
| Connection | |
| Type of electric connection | Pin |
| Electrical | |
| Number of phases | 3 |
| Rated surge voltage | - |
| Rated permanent current Iu | 100 A |
| Conditioned rated short-circuit current Iq | - |
| Number of poles | 3 |
| Max. rated operation voltage Ue | 415 V |
| Rated short-time withstand current lcw | - |
| Application | |
| Suitable for devices with auxiliary switch | Yes |
| Suitable for devices with N-conductor | No |
| Suitable for number of devices | 19 |
| Package 1 | |
| volume | 456,75 cm3 |
| weight | 578 g |
| length | 101,5 cm |
| width | 3 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606480485152 |
| Package 2 | |
| volume | 5311,35 cm3 |
| weight | 3,09 kg |
| length | 9 cm |
| width | 107,3 cm |
| qmax | 5 |
| qmin | 5 |
| um | BX |
| gtin | 13606480485159 |
| Package 3 | |
| volume | 720000 cm3 |
| weight | 178,968 kg |
| length | 120 cm |
| width | 80 cm |
| qmax | 270 |
| qmin | 270 |
| um | PF |
| gtin | 73606480485151 |
