LINERGY DX 4P BLOCK 125A 6M 52 gauri
Documente
Specificatii
| Measurements | |
| Width | 108 mm |
| Depth | 48 mm |
| Height | 127 mm |
| Connection | |
| Number of inputs | - |
| Number of outputs | - |
| Conductor cross section, output | - |
| Conductor cross section, input | - |
| Conductor cross section, output AWG | - |
| Conductor cross section, input AWG | - |
| Connection type | Without screws |
| Application | |
| Suitable for stranded conductors | No |
| Suitable for fine strand conductors | No |
| Suitable for solid conductors | No |
| Suitable for extra fine-strand conductors | No |
| Suitable for fine strand conductors without cable end sleeve | No |
| Suitable for extra fine-strand conductors without cable end sleeve | No |
| Electrical | |
| Nominal current | 125 A |
| Number of poles | 4 |
| Options | |
| Contact safe | Yes |
| Mounting/installation | |
| Mounting method | DIN-rail/screw |
| Package 1 | |
| volume | 1481,76 cm3 |
| weight | 474 g |
| length | 13,5 cm |
| width | 11,2 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606481870896 |
| Package 2 | |
| volume | 8704,8 cm3 |
| weight | 2,541 kg |
| length | 49,6 cm |
| width | 15 cm |
| qmax | 5 |
| qmin | 5 |
| um | BX |
| gtin | 13606481870893 |
| Package 3 | |
| volume | 912000 cm3 |
| weight | 225 kg |
| length | 120 cm |
| width | 80 cm |
| qmax | 420 |
| qmin | 420 |
| um | PF |
