| Model/type |
| With message indication |
Yes |
| With numeric keyboard |
No |
| Number of grey-scales/blue-scales of display |
0 |
| With alpha numeric keyboard |
No |
| Number of buttons with LED |
0 |
| With message system (incl. buffer and confirmation) |
Yes |
| Type of display |
STN |
| With printer output |
No |
| With recipes |
No |
| Setting/control |
| Number of function buttons, programmable |
4 |
| Number of system buttons |
6 |
| Communication |
| Number of interfaces PROFINET |
0 |
| Number of HW-interfaces parallel |
0 |
| Supporting protocol for SERCOS |
No |
| Number of HW-interfaces other |
1 |
| Number of HW-interfaces serial TTY |
0 |
| Number of HW-interfaces USB |
0 |
| Number of HW-interfaces wireless |
0 |
| Supporting protocol for INTERBUS-Safety |
No |
| Supporting protocol for AS-Interface Safety at Work |
No |
| Supporting protocol for DeviceNet Safety |
No |
| Supporting protocol for EtherNet/IP |
No |
| Supporting protocol for Foundation Fieldbus |
No |
| With SW interfaces |
No |
| Supporting protocol for SafetyBUS p |
No |
| Supporting protocol for PROFINET CBA |
No |
| Supporting protocol for PROFINET IO |
No |
| Supporting protocol for PROFIsafe |
No |
| Supporting protocol for ASI |
No |
| Supporting protocol for PROFIBUS |
No |
| Supporting protocol for TCP/IP |
No |
| Supporting protocol for KNX |
No |
| Supporting protocol for CAN |
No |
| Supporting protocol for INTERBUS |
No |
| Supporting protocol for DeviceNet |
No |
| Supporting protocol for Modbus |
No |
| Supporting protocol for Data-Highway |
No |
| Supporting protocol for LON |
No |
| Supporting protocol for other bus systems |
No |
| Supporting protocol for SUCONET |
No |
| Number of HW-interfaces RS-422 |
0 |
| Number of HW-interfaces RS-485 |
0 |
| Number of HW-interfaces industrial Ethernet |
0 |
| Number of HW-interfaces RS-232 |
0 |
| Performance |
| Usable project memory/user memory |
- |
| Protection |
| Degree of protection (NEMA), front side |
- |
| Degree of protection (IP), front side |
IP65/IP67 |
| Options |
| Radio standard GPRS |
No |
| Process value representation (output) possible |
No |
| Process default value (input) possible |
No |
| Radio standard GSM |
No |
| Mobile communications standard 3G (UMTS) |
No |
| Additional software components, loadable |
Yes |
| Radio standard Bluetooth |
No |
| Radio standard WLAN 802.11 |
No |
| Colour display |
No |
| IO link master |
No |
| Other |
| Number of password levels |
1 |
| Number of online languages |
6 |
| Touch technology |
None |
| Number of pixels, horizontal |
240 |
| Number of pixels, vertical |
160 |
| Operating conditions |
| Operating temperature |
-15 °C |
| Measurements |
| Screen diagonal |
2.75 in |
| Built-in depth |
63 mm |
| Width of the front |
126 mm |
| Height of the front |
80 mm |
| Electrical |
| Voltage type (supply voltage) |
DC |
| Supply voltage AC 50 Hz |
- |
| Supply voltage AC 60 Hz |
- |
| Supply voltage DC |
5 V |
| Colour |
| Number of colours of the display |
1 |
| Mounting/installation |
| Suitable for rail mounting |
Yes |
| Wall mounting/direct mounting |
Yes |
| Application |
| Suitable for safety functions |
No |
| Package 1 |
| volume |
2097,9 cm3 |
| weight |
326 g |
| length |
18,5 cm |
| width |
14 cm |
| qmax |
1 |
| qmin |
1 |
| um |
C62 |
| gtin |
3606480752216 |
| Package 2 |
| volume |
36000 cm3 |
| weight |
4,74 kg |
| length |
40 cm |
| width |
30 cm |
| qmax |
12 |
| qmin |
12 |
| um |
CT |
| gtin |
23606480752210 |
