| Communication |
| Supporting protocol for IEC 60870 |
No |
| Supporting protocol for DNP3 |
No |
| Supporting protocol for SERCOS |
No |
| Number of interfaces PROFINET |
0 |
| Number of HW-interfaces parallel |
0 |
| Number of HW-interfaces other |
0 |
| Number of HW-interfaces USB |
1 |
| With optical interface |
No |
| Number of HW-interfaces wireless |
0 |
| Supporting protocol for INTERBUS-Safety |
No |
| Supporting protocol for AS-Interface Safety at Work |
No |
| Supporting protocol for DeviceNet Safety |
No |
| Supporting protocol for EtherNet/IP |
No |
| Supporting protocol for Foundation Fieldbus |
No |
| Supporting protocol for SafetyBUS p |
No |
| Supporting protocol for PROFINET CBA |
No |
| Supporting protocol for PROFINET IO |
No |
| Supporting protocol for PROFIsafe |
No |
| Supporting protocol for ASI |
No |
| Supporting protocol for PROFIBUS |
No |
| Supporting protocol for TCP/IP |
No |
| Supporting protocol for KNX |
No |
| Supporting protocol for CAN |
No |
| Supporting protocol for INTERBUS |
No |
| Supporting protocol for IEC 61850 Ethernet |
No |
| Supporting protocol for DeviceNet |
No |
| Supporting protocol for Modbus |
Yes |
| Supporting protocol for Data-Highway |
No |
| Supporting protocol for LON |
No |
| Supporting protocol for other bus systems |
No |
| Supporting protocol for SUCONET |
No |
| Number of HW-interfaces RS-422 |
0 |
| Number of HW-interfaces RS-485 |
1 |
| Number of HW-interfaces industrial Ethernet |
0 |
| Number of HW-interfaces RS-232 |
1 |
| Approval/certification |
| SIL according to IEC 61508 |
None |
| Connection |
| Number of relay outputs |
0 |
| Number of digital outputs |
16 |
| Number of digital inputs |
24 |
| Number of analogue outputs |
0 |
| Number of analogue inputs |
2 |
| Other |
| Max. number of time switches |
255 |
| Processing time (1K, binary operation) |
0.2 ms |
| Appendant operation agent (Ex ia) |
No |
| Appendant operation agent (Ex ib) |
No |
| Options |
| System accessory |
No |
| Additional program memory possible |
Yes |
| Radio standard GPRS |
No |
| Redundancy |
No |
| Radio standard GSM |
No |
| Mobile communications standard 3G (UMTS) |
No |
| Long-Term Evolution (LTE) |
No |
| Radio standard Bluetooth |
No |
| Radio standard WLAN 802.11 |
No |
| IO link master |
No |
| Rack-assembly possible |
No |
| Performance |
| Performance level according to EN ISO 13849-1 |
None |
| Measurements |
| Height |
103.6 mm |
| Width |
163 mm |
| Depth |
75.9 mm |
| Memory size |
512 kByte |
| Protection |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
None |
| Model/type |
| With display |
No |
| Model |
Compact |
| Type of memory |
RAM |
| Electrical |
| Voltage type (supply voltage) |
DC |
| Supply voltage AC 50 Hz |
- |
| Supply voltage AC 60 Hz |
- |
| Supply voltage DC |
19.2 V |
| Mounting/installation |
| Front built-in possible |
No |
| Suitable for rail mounting |
Yes |
| Wall mounting/direct mounting |
Yes |
| Application |
| Suitable for safety functions |
No |
| Package 1 |
| volume |
3363,36 cm3 |
| weight |
832 g |
| length |
11,2 cm |
| width |
21 cm |
| qmax |
1 |
| qmin |
1 |
| um |
C62 |
| gtin |
3606485408637 |
| Package 2 |
| volume |
72000 cm3 |
| weight |
10,624 kg |
| length |
60 cm |
| width |
40 cm |
| qmax |
12 |
| qmin |
12 |
| um |
CT |
| gtin |
43606485408635 |
