Cod produs: A9TYB4240

Autentificati-va pentru a vedea pretul.

Producator: Schneider Electric

Set: 1 bucati

3606481906045

Acti9 AFDD, Bloc auxiliar detectie arc electric si protectie diferentiala, 40A, 30mA tip A-SI, pentru iC60 2P

Electrical
Nominal voltage	230 V
Nominal current	40 A
Rated insulation voltage Ui	250 V
Surge current capacity	3 kA
Rated fault current	0.03 A
Number of poles	2
Rated impulse withstand voltage Uimp	4 kV
Leakage current type	A
Other
Max. delay time	0 ms
Frequency	50 Hz
Pollution degree	2
Setting/control
Delay adjustable	No
Rated fault current adjustable	No
Connection
Connectable conductor cross section solid-core	1 mm²
Connectable conductor cross section multi-wired	1 mm²
Operating conditions
Ambient temperature during operating	-25 °C
Model/type
With interlocking device	No
Protection
Degree of protection (IP)	IP20
Options
Anti-nuisance tripping version	Yes
Package 1
volume	578,592 cm3
weight	126 g
length	11,2 cm
width	8,2 cm
qmax	1
qmin	1
um	C62
gtin	3606481906045
Package 2
volume	18000 cm3
weight	2,963 kg
length	40 cm
width	30 cm
qmax	17
qmin	17
um	CT
gtin	43606481906043
Package 3
volume	432000 cm3
weight	55,467 kg
length	120 cm
width	80 cm
qmax	272
qmin	272
um	PF
