| Communication |
| Supporting protocol for SERCOS |
No |
| Supporting protocol for INTERBUS-Safety |
No |
| Supporting protocol for AS-Interface Safety at Work |
No |
| Supporting protocol for DeviceNet Safety |
No |
| Supporting protocol for EtherNet/IP |
No |
| Supporting protocol for Foundation Fieldbus |
No |
| Supporting protocol for SafetyBUS p |
No |
| Supporting protocol for PROFINET CBA |
No |
| Supporting protocol for PROFINET IO |
No |
| Supporting protocol for PROFIsafe |
No |
| Supporting protocol for ASI |
No |
| Supporting protocol for PROFIBUS |
No |
| Supporting protocol for TCP/IP |
No |
| Supporting protocol for KNX |
No |
| Supporting protocol for CAN |
No |
| Supporting protocol for INTERBUS |
No |
| Supporting protocol for DeviceNet |
No |
| Supporting protocol for Modbus |
No |
| Supporting protocol for Data-Highway |
No |
| Supporting protocol for LON |
No |
| Supporting protocol for other bus systems |
Yes |
| Supporting protocol for SUCONET |
No |
| Approval/certification |
| SIL according to IEC 61508 |
None |
| Options |
| System accessory |
Yes |
| Radio standard GPRS |
No |
| Radio standard GSM |
No |
| Mobile communications standard 3G (UMTS) |
No |
| Radio standard LTE |
No |
| Radio standard eGPRS |
No |
| Radio standard Bluetooth |
No |
| Radio standard WLAN 802.11 |
No |
| IO link master |
No |
| Rack-assembly possible |
No |
| Performance |
| Performance level according to EN ISO 13849-1 |
None |
| Model/type |
| With potential separation |
Yes |
| Connection |
| Fieldbus connection over separate bus coupler possible |
No |
| Measurements |
| Height |
25 mm |
| Width |
45 mm |
| Depth |
85 mm |
| Protection |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
None |
| Degree of protection (IP) |
IP20 |
| Electrical |
| Voltage type (supply voltage) |
DC |
| Supply voltage AC 50 Hz |
- |
| Supply voltage AC 60 Hz |
- |
| Supply voltage DC |
24 V |
| Other |
| Appendant operation agent (Ex ia) |
No |
| Appendant operation agent (Ex ib) |
No |
| Mounting/installation |
| Front built-in possible |
Yes |
| Suitable for rail mounting |
No |
| Wall mounting/direct mounting |
No |
| Application |
| Suitable for safety functions |
No |
| Package 1 |
| volume |
150,48 cm3 |
| weight |
46 g |
| length |
9,5 cm |
| width |
4,8 cm |
| qmax |
1 |
| qmin |
1 |
| um |
C62 |
| gtin |
3389110365504 |
| Package 2 |
| volume |
18000 cm3 |
| weight |
3,167 kg |
| length |
40 cm |
| width |
30 cm |
| qmax |
62 |
| qmin |
62 |
| um |
CT |
| gtin |
43389110365502 |
