125NHG01BI

Cod produs: 125NHG01BI

Autentificati-va pentru a vedea pretul.

Producator: Eaton

Set: 1 bucati

5027590429993

NH FUSE 125A 500V GL/GG SIZE 01

Electrical
Fuse construction type according to IEC 60269	NH01
Voltage type	AC
Rated current	125
Rated voltage AC	500
Rated voltage DC	-
Power loss at rated current	-
Performance
Rated switching capacity AC	-
Rated switching capacity DC	-
Other
Utilization category according to IEC 60269	gG
Model/type
Type of fuse status indicator	Combination fuse status indicator
Options
Insulated metal gripping lugs (IMGL)	Yes
Package 1
volume	0,0002349
weight	0,294667
length	0,137
width	0,032
qmax	1
qmin	1
um	CS
gtin	5027590429993
Package 2
volume	0,00095023
weight	0,884
length	0,137
width	0,102
qmax	3
qmin	3
um	CT
gtin	5027590145930
Package 3
volume	0,01460875
weight	11,208
length	0,325
width	0,29
qmax	36
qmin	36
um	CT
gtin	5027590341714
Dimensions of product
Volume	0,0002349
Weight	0,295
Length	0,135
Width	0,03
Depth	0,058

Afiseaza mai multe specificatii
