Descriere
Fuse-link, high speed, 1250 A, AC 1250 V, 2 x size 3, 74 x 52 x 167 mm, aR, IEC, single indicator
Specificatii
| Electrical | |
| Fuse system according to IEC 60269 | Other |
| Fuse construction type according to IEC 60269 | Other |
| Rated voltage AC | 1250 |
| Rated voltage DC | - |
| Rated current | 1250 |
| Breaking capacity | 125 |
| Power loss at rated current | 230 |
| Model/type | |
| Type of current | AC |
| Colour code | None |
| Type of fuse status indicator | Centre fuse status indicator |
| Other | |
| Utilization category according to IEC 60269 | aR |
| Mounting/installation | |
| Mounting holes | M10 |
| Connection | |
| Centre-to-centre distance of connections | 75 |
| Package 1 | |
| volume | 0,0010656 |
| weight | 2,8 |
| length | 0,09 |
| width | 0,16 |
| qmax | 1 |
| qmin | 1 |
| um | CS |
| gtin | 5996516045336 |
| Dimensions of product | |
| Volume | 0,001066 |
| Weight | 2,6 |
| Length | 0,16 |
| Width | 0,09 |
| Depth | 0,074 |
