Descriere
IEC busbar support, 60 mm system, rated operational current Ie=630A, poles=2, can be used for 12x5/10, 15x5/10, 20x5/10, 25x5/10 and 30x5/10, with slider to adapt to the respective busbar size, with screw block inside, temperature resistant to 120 °C, track resistance CTI 200, self-extinguishing to UL 94, RAL 7035, thermoplastic, silicon free, chlorine free, halogen free, distance between busbar supports corresponding to short-circuit strength diagram, UL approved
Documente
Specificatii
| Electrical | |
| Number of poles | 2 |
| Max. rated current | 630 |
| Measurements | |
| Busbar distance | 60 |
| Package 1 | |
| volume | 0,000164 |
| weight | 0,114 |
| length | 0,022 |
| width | 0,166 |
| qmax | 1 |
| qmin | 1 |
| um | CS |
| gtin | 4015081069224 |
| Package 2 | |
| volume | 0,002871 |
| weight | 1,14 |
| length | 0,18 |
| width | 0,145 |
| qmax | 10 |
| qmin | 10 |
| um | CT |
| gtin | 9010238237063 |
| Dimensions of product | |
| Volume | 0,000164 |
| Weight | 0,109 |
| Length | 0,02 |
| Width | 0,164 |
| Depth | 0,05 |
