Descriere
Fuse accessory, Switch disconnector, low voltage, 630 A, AC 690 V, NH3, AC21B, 3P, IEC, vertical, 185 mm busbar mounting, single phase switching, M12 screws with pressed nuts, NH3 fuse-links, IEC 60947-1, IEC 60947-3, IP30
Documente
Specificatii
| Model/type | |
| Model | Fuse switch disconnector |
| Options | |
| Double interrupting | No |
| Electrical | |
| Rated permanent current Iu | 630 |
| Max. rated operation voltage Ue AC | 690 |
| Conditioned rated short-circuit current Iq | 0.08 |
| Number of poles | 3 |
| Measurements | |
| Distance between rail centre, 40 mm | No |
| Distance between rail centre, 50 mm | No |
| Distance between rail centre, 60 mm | No |
| Distance between rail centre, 100 mm | No |
| Distance between rail centre, 185 mm | Yes |
| Construction size fuse insert | NH3 |
| Connection | |
| Type of electrical connection of main circuit | Screw connection |
| Other | |
| Release indication | None |
| Package 1 | |
| volume | 0,014479 |
| weight | 6,502 |
| length | 0,195 |
| width | 0,11 |
| qmax | 1 |
| qmin | 1 |
| um | CS |
| gtin | 5027590336079 |
| Dimensions of product | |
| Volume | 0,014479 |
| Weight | 6,234 |
| Length | 0,195 |
| Width | 0,11 |
| Depth | 0,675 |
