Descriere
HRC blade type cartridge fuse - type gG - size 0 - 160 A - with indicator
Documente
Fisa tehnica
Specificatii
| Other | |
| Utilization category according to IEC 60269 | gG |
| Performance | |
| Rated switching capacity AC | - |
| Rated switching capacity DC | - |
| Model/type | |
| Type of fuse status indicator | Top fuse status indicator |
| Electrical | |
| Voltage type | AC/DC |
| Fuse construction type according to IEC 60269 | NH0 |
| Power loss at rated current | - |
| Rated voltage AC | 500 |
| Rated current | 160 |
| Rated voltage DC | 48 |
| Options | |
| Insulated metal gripping lugs (IMGL) | - |
| Package 1 | |
| volume | 0,001774 |
| weight | 0,827 |
| length | 0,077 |
| width | 0,144 |
| qmax | 3 |
| qmin | 3 |
| um | BX |
| gtin | 3414971648517 |
| Package 2 | |
| volume | 0,020874 |
| weight | 8,192 |
| length | 0,176 |
| width | 0,298 |
| qmax | 30 |
| qmin | 30 |
| um | CT |
| gtin | 3414970341938 |
| Package 3 | |
| volume | 0,4068 |
| weight | 81,92 |
| length | 0,339 |
| width | 1,2 |
| qmax | 300 |
| qmin | 300 |
| um | PF |
| gtin | 3414970553836 |
