Descriere
Power supply - external - 12 V DC - for DMX³ electronic protection units
Documente
Fisa tehnica
Instructiuni
Specificatii
| Electrical | |
| Power output | - |
| 3rd secondary output voltage | 12 |
| Max. output current 3 | 0.25 |
| Output voltage stabilized | No |
| Rated supply voltage AC 50 Hz | 21.6 |
| Nominal value output current 3 | 0.25 |
| Rated supply voltage AC 60 Hz | 21.6 |
| Nominal value output current 2 | 0.25 |
| Rated supply voltage DC | 21.6 |
| Nominal value output voltage 2 | 12 |
| Nominal value output voltage 1 | 12 |
| Max. output current 1 | 0.25 |
| Nominal value output current 1 | 0.25 |
| Max. output current 2 | 0.25 |
| Nominal value output voltage 3 | 12 |
| Voltage type (supply voltage) | AC/DC |
| 2nd secondary output voltage | 12 |
| 1st secondary output voltage | 21.6 |
| Secondary voltage adjustable | No |
| Power consumption | - |
| Measurements | |
| Height | 105 |
| Width in number of modular spacings | 2 |
| Built-in height | 105 |
| Depth | 50 |
| Width | 35.6 |
| Built-in width | - |
| Protection | |
| Degree of protection (IP) | IP20 |
| Degree of protection (NEMA) | - |
| Performance | |
| Performance level according to EN ISO 13849-1 | - |
| Application | |
| Suitable for safety functions | - |
| Mounting/installation | |
| Suitable for rail mounting | Yes |
| Direct mounting possible | Yes |
| Suitable for wall mounting | Yes |
| Options | |
| Short-circuit-proof | Yes |
| Suitable for distribution board | Yes |
| Stabilized | Yes |
| Approval/certification | |
| SIL according to IEC 61508 | - |
| Connection | |
| Type of electric connection | Screw connection |
| Package 1 | |
| volume | 0,000556 |
| weight | 0,084 |
| length | 0,083 |
| width | 0,062 |
| qmax | 1 |
| qmin | 1 |
| um | BX |
| gtin | 3245060288068 |
| Package 2 | |
| volume | 0,003488 |
| weight | 0,332 |
| length | 0,123 |
| width | 0,137 |
| qmax | 3 |
| qmin | 3 |
| um | CT |
| gtin | 3414971548619 |
| Package 3 | |
| volume | 0,4908 |
| weight | 25,896 |
| length | 0,409 |
| width | 1,2 |
| qmax | 234 |
| qmin | 234 |
| um | PF |
| gtin | 3414971548626 |
| Dimensions of product | |
| Length | 0,105 |
| Width | 0,0356 |
| Depth | 0,05 |
