Descriere
RCBO, Icn=10kA, 1+Npoli, car. C, In=6A, IΔn=30mA, tip A
Specificatii
| Model/type | |
| Number of poles (total) | 2 |
| Number of protected poles | 1 |
| With interlocking device | No |
| Electrical | |
| Rated voltage | 230 V |
| Rated insulation voltage Ui | 500 V |
| Rated impulse withstand voltage Uimp | 4 kV |
| Rated current | 6 A |
| Rated fault current | 0.03 A |
| Leakage current type | A |
| Current limiting class | 3 |
| Power loss | 1.8 W |
| Rated short-circuit breaking capacity according to EN 61009 | 10 kA |
| Rated short-circuit breaking capacity according to IEC 60947-2 | - kA |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 | 10 kA |
| Surge current capacity | 3 kA |
| Voltage type | AC |
| Release characteristic | C |
| Overvoltage category | 3 |
| Connection | |
| Disconnection characteristic | Undelayed |
| Connectable conductor cross section solid-core | 1.5 mm² |
| Connectable conductor cross section multi-wired | - mm² |
| Other | |
| Frequency | 50/60 Hz |
| Pollution degree | 2 |
| Options | |
| Concurrently switching neutral conductor | Yes |
| Anti-nuisance tripping version | No |
| Operating conditions | |
| Ambient temperature during operating | -25 °C |
| Measurements | |
| Width in number of modular spacings | 2 |
| Built-in depth | 77 mm |
| Mounting/installation | |
| Flush-mounted installation | No |
| Protection | |
| Degree of protection (IP) | IP20 |
