Descriere
Întreruptor-separator, lăţime 1 modul, 4-poli, 25A
Specificatii
| Model/type | |
| Switching function | Off switch |
| With signal lamp | No |
| Lamp type | - |
| Connection | |
| Number of contacts as normally open contact | - |
| Number of contacts as normally closed contact | - |
| Number of contacts as change-over contact | - |
| Electrical | |
| Number of poles | 4 |
| Rated current | 25 A |
| Rated voltage | 400 V |
| Min. rated voltage | - V |
| Rated switching capacity | 0.5 kA |
| Short-circuit breaking capacity (Icw) | 0.3 kA |
| Voltage type | AC |
| Max. lamp power | - W |
| Colour | |
| Colour calotte | Grey |
| Other | |
| Lamp socket | - |
| Imprint/indication | - |
| Measurements | |
| Width in number of modular spacings | 1 |
| Built-in depth | 80 mm |
| Protection | |
| Degree of protection (IP) | IP20 |
