Ex9M1S TM 32 3P EU Întreruptor automat, AC, dimensiune cadru M1, Icu=Ics=36kA, In=32A, 3P
Cod produs: 111794
Descriere
Întreruptor automat, AC, dimensiune cadru M1, Icu=Ics=36kA, In=32A, 3P
Specificatii
| Electrical | |
| Rated permanent current Iu | 32 A |
| Rated voltage | 415 V |
| Rated short-circuit breaking capacity Icu at 400 V, 50 Hz | 36 kA |
| Overload release current setting | 22 A |
| Adjustment range short-term delayed short-circuit release | - A |
| Adjustment range undelayed short-circuit release | 320 A |
| Power loss | 13.8 W |
| With integrated under voltage release | No |
| Number of poles | 3 |
| Other | |
| Device construction | Built-in device fixed built-in technique |
| Protection | |
| Integrated earth fault protection | No |
| Complete device with protection unit | Yes |
| Degree of protection (IP) | IP20 |
| Connection | |
| Type of electrical connection of main circuit | Frame clamp |
| Number of auxiliary contacts as normally closed contact | 0 |
| Number of auxiliary contacts as normally open contact | 0 |
| Number of auxiliary contacts as change-over contact | 0 |
| Position of connection for main current circuit | Front side |
| Mounting/installation | |
| Suitable for DIN rail (top hat rail) mounting | No |
| DIN rail (top hat rail) mounting optional | Yes |
| Model/type | |
| With switched-off indicator | No |
| Type of control element | Rocker lever |
| Motor drive integrated | No |
| Options | |
| Motor drive optional | Yes |
