Ex9UEP1+2 6.25R 2P 500 M EU Modul plug-in cu contact semnalizare de la distanta, plug-in pentru Ex9U
Cod produs: 111772
Descriere
Modul plug-in cu contact semnalizare de la distanta, plug-in pentru Ex9UEP1+2 1P, Clasa 1+2, In=6,25kA, 500 V DC, latime 2 module
Specificatii
| Options | |
| System configuration DC | Yes |
| System configuration IT | No |
| System configuration TN | No |
| System configuration TN-C | No |
| System configuration TN-C-S | No |
| System configuration TN-S | No |
| System configuration TT | No |
| System configuration other | Yes |
| Remote signalling | Yes |
| Electrical | |
| Number of poles | 1 |
| Lightning impulse current (10/350 µs) | 6.25 kA |
| Max. continuous voltage AC | - V |
| Max. continuous voltage DC | 500 V |
| Nominal voltage AC | - V |
| Nominal voltage DC | 500 V |
| Max. PV-voltage | - V |
| Voltage protection level | - kV |
| Voltage protection level L-N | - kV |
| Voltage protection level L-PE | - kV |
| Voltage protection level N-PE | - kV |
| Voltage protection level (DC+ - DC-) | - kV |
| Voltage protection level (DC+/DC- - PE) | - kV |
| Follow current extinguishing capability | - kA |
| Max. overcurrent protection device, parallel connection (fuse) | - A |
| Max. overcurrent protection device, series connection (fuse) | - A |
| Voltage switching spark gap technology | - |
| Overcurrent protected voltage tapping | - |
| Other | |
| Specific energy (W/R) | - kJ/Ohm |
| Signalling at the device | Optical |
| Test class | Type 1 + 2 |
| Mounting/installation | |
| Mounting method | On basic element |
| Measurements | |
| Construction size | 1 modular spacing |
| Connection | |
| Max. conductor cross section solid (solid, stranded) | 25 mm² |
| Max. conductor cross section flexible (fine-strand) | 25 mm² |
| Model/type | |
| Integrated backup fuse | No |
| Protection | |
| Energy-coordinated protection effect with regard to the terminal equipment | No |
| Degree of protection (IP) | IP20 |
