Descriere
Acti9 iSW este un intrerupator de sarcina modular si fiabil. este un 2P, curentul nominal este de 20A, iar tensiunea de functionare este de 415Vca. Rezistenta electrica creste pana la 30000 de cicluri, iar rezistenta mecanica creste pana la 300000 de cicluri. Temperatura de functionare este de la -20°C la +50°C. Temperatura de depozitare este -40°C pana la +70°C. Gradul de protectie este IP20 si IP40 intr-o carcasa. Este montat pe sina DIN. Latimea in gauri de 9mm este de 2. Dimensiunile sunt (W) 18mm x (H) 77mm x (D) 70mm. Acest intrerupator de sarcina este utilizat pentru control. Acest produs respecta standardul EN/IEC 60669-2-4.
Documente
Fisa tehnica
Altele
Declaratie de conformitate
Alte surse
Specificatii
| Electrical | |
| Rated current | 20 A |
| Rated voltage | 415 V |
| Rated switching capacity | - |
| Voltage type | AC |
| Short-circuit breaking capacity (Icw) | - |
| Number of poles | 2 |
| Min. rated voltage | 415 V |
| Max. lamp power | - |
| Measurements | |
| Built-in depth | 75.5 mm |
| Width in number of modular spacings | 1 |
| Model/type | |
| With signal lamp | No |
| Switching function | Off switch |
| Lamp type | - |
| Other | |
| Imprint/indication | Other |
| Lamp socket | - |
| Colour | |
| Colour calotte | White |
| Connection | |
| Number of contacts as normally open contact | 2 |
| Number of contacts as change-over contact | 0 |
| Number of contacts as normally closed contact | 0 |
| Approval/certification | |
| Forced segregation according to DIN VDE 0113 | Yes |
| Protection | |
| Degree of protection (IP) | IP40 |
| Package 1 | |
| volume | 97,5 cm3 |
| weight | 66 g |
| length | 6,5 cm |
| width | 2 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606480088681 |
| Package 2 | |
| volume | 1713,618 cm3 |
| weight | 842 g |
| length | 22,2 cm |
| width | 9,3 cm |
| qmax | 12 |
| qmin | 12 |
| um | BX |
| gtin | 13606480088688 |
| Package 3 | |
| volume | 36000 cm3 |
| weight | 10,554 kg |
| length | 40 cm |
| width | 30 cm |
| qmax | 144 |
| qmin | 144 |
| um | CT |
| gtin | 43606480088689 |
