Descriere
Bloc De Contacte Auxiliar Tesys - 4 Nc - Borne Cu Arc
Documente
Fisa tehnica
Specificatii
| Connection | |
| Number of contacts as normally open contact | 0 |
| Number of contacts as change-over contact | 0 |
| Number of contacts as normally closed contact | 4 |
| Type of electric connection | Spring clamp connection |
| Model/type | |
| Model | Clip-on |
| Lamp holder | - |
| Number of fault-signal switches | 0 |
| Electrical | |
| Rated operation current Ie at AC-15, 230 V | 10 A |
| Mounting/installation | |
| Mounting method | Front fastening |
| Package 1 | |
| volume | 110,823 cm3 |
| weight | 42 g |
| length | 5,3 cm |
| width | 5,1 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3389110244960 |
| Package 2 | |
| volume | 1493,856 cm3 |
| weight | 448 g |
| length | 18,9 cm |
| width | 15,2 cm |
| qmax | 10 |
| qmin | 10 |
| um | BX |
| gtin | 53389110244965 |
