Descriere
Bloc Terminal Cu Impamantare Linergy2.5Mm² 1Nivel 1X1 Conex. Cu ArcVerde-Galben
Documente
Fisa tehnica
Altele
Declaratie de conformitate
Specificatii
| Connection | |
| Number of levels | 1 |
| Type of electrical connection 2 | Screw connection |
| Type of electrical connection 1 | Screw connection |
| Connectable conductor cross section solid-core | 16 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve | 25 mm² |
| Connectable conductor cross section multi-wired | 25 mm² |
| Number of clamp positions per level | 2 |
| Connectable conductor cross section fine-strand without cable end sleeve | 25 mm² |
| Colour | |
| Colour | Grey |
| Electrical | |
| Rated voltage | 1000 V |
| Rated current In | 192 A |
| Measurements | |
| Width | 20.3 mm |
| Depth | 70.5 mm |
| Height | 87.5 mm |
| Options | |
| Internally connected stages | No |
| Protection | |
| Inflammability class of insulation material according to UL94 | V0 |
| Explosion-tested version 'Ex e' | Yes |
| Mounting/installation | |
| Mounting method | DIN rail (top hat rail) 35 mm |
| Operating conditions | |
| Closing plate required | No |
| Operating temperature | -40 °C |
| Material | |
| Material insulation body | Thermoplastic |
| Package 1 | |
| volume | 1914,98 cm3 |
| weight | 145 g |
| length | 18,1 cm |
| width | 11,5 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606480532238 |
| Package 2 | |
| volume | 3829,96 cm3 |
| weight | 1,659 kg |
| length | 36,2 cm |
| width | 11,5 cm |
| qmax | 10 |
| qmin | 10 |
| um | BX |
| gtin | 13606480532235 |
| Package 3 | |
| volume | 360000 cm3 |
| weight | 92,968 kg |
| length | 80 cm |
| width | 60 cm |
| qmax | 480 |
| qmin | 480 |
| um | CT |
| gtin | 73606480532237 |
