Contactor Reversibil Tesys Lc2-K - 4 Poli - Ac-1 20 A - Bobina 110 V C.A.
Documente
Fisa tehnica
Altele
Specificatii
| Connection | |
| Type of electrical connection of main circuit | Screw connection |
| Number of normally closed contacts as main contact | 0 |
| Number of normally open contacts as main contact | 4 |
| Type of electrical connection for auxiliary- and control current circuit | Screw connection |
| Electrical | |
| Rated control supply voltage AC 50 Hz | 110 V |
| Rated control supply voltage AC 60 Hz | 110 V |
| Rated operation power at AC-3, 400 V | - |
| Rated operation power NEMA | - |
| Rated operation current Ie at AC-1, 400 V | 20 A |
| Rated operation current Ie at AC-3, 400 V | 12 A |
| Voltage type for actuating | AC |
| Rated control supply voltage DC | - |
| Mounting/installation | |
| Suitable for rail mounting | No |
| Protection | |
| Degree of protection (IP) | IP20 |
| Degree of protection (NEMA) | Other |
| Model/type | |
| Function | Changeover contactor |
| Package 1 | |
| volume | 342,24 cm3 |
| weight | 390 g |
| length | 9,2 cm |
| width | 6,2 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3389118096769 |
| Package 2 | |
| volume | 9000 cm3 |
| weight | 2,54 kg |
| length | 40 cm |
| width | 15 cm |
| qmax | 6 |
| qmin | 6 |
| um | CT |
| gtin | 13389118096766 |
| Package 3 | |
| volume | 360000 cm3 |
| weight | 89,28 kg |
| length | 60 cm |
| width | 80 cm |
| qmax | 192 |
| qmin | 192 |
| um | PF |
