Descriere
Patron Siguranta Din 1 Cu Lame - Am 250 A - Fara Indicatie
Documente
Specificatii
| Electrical | |
| Rated current | 250 A |
| Power loss at rated current | 17.5 W |
| Rated voltage AC | 690 V |
| Rated switching capacity | 80 kA |
| Voltage type | AC |
| Rated voltage DC | - |
| Fuse construction type according to IEC 60269 | NH1 |
| Other | |
| Utilization category according to IEC 60269 | aM |
| Model/type | |
| Type of fuse status indicator | None |
| Options | |
| Insulated metal gripping lugs (IMGL) | No |
| Package 1 | |
| volume | 358,8 cm3 |
| weight | 398 g |
| length | 13,8 cm |
| width | 4 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3389110503302 |
| Package 2 | |
| volume | 1270,08 cm3 |
| weight | 1,242 kg |
| length | 14,4 cm |
| width | 12,6 cm |
| qmax | 3 |
| qmin | 3 |
| um | BX |
| gtin | 13389110503309 |
| Package 3 | |
| volume | 18000 cm3 |
| weight | 9,038 kg |
| length | 40 cm |
| width | 30 cm |
| qmax | 21 |
| qmin | 21 |
| um | CT |
| gtin | 43389110503300 |
