Descriere
Modernizati spatiul cu intrerupatorul simplu 10 AX Noua Unica. Dispozitivul utilizeaza borne fara suruburi. Acesta se fixeaza prin clipsare. Dispozitivul are 1 modul. Dispozitivul are 1 modul, iar tensiunea de functionare este de 250 V c.a. la 50 / 60Hz. Culoarea dispozitivului este alba si are un finisaj lucios. Acest intrerupator este certificat AENOR, CE, VDE, NF. Pentru instalare, butoanele de eliberare ale bornei fara suruburi permit o ergonomie mai buna, economisind timp, si au culori diferite pentru identificare usoara. Dimensiunile produsului sunt (Latime) 22.5m x (Inaltime) 45 mm x (Adancime) 34.5 mm. Adancimea de incastrare este de 21,5 mm. Are grad de protectie IP4X. Dispozitivul functioneaza la temperaturi cuprinse intre -5°C si 40°C. Noul Unica este proiectata cu caracteristici inteligente pentru a fi flexibila, usor si rapid de instalat, oferind solutii pentru toate cerintele clientilor. Noua Unica este o gama modulara care ofera o gama larga de produse si functii, cu o estetica eleganta si atemporala, care se integreaza bine cu alte instalatii. Este proiectata cu caracteristici inteligente pentru a fi flexibila, usor de inteles si rapid de instalat, oferind solutii convenabile pentru cerintele clientilor.
Documente
Specificatii
| Material | |
| Surface protection | Other |
| Surface finishing | Matt |
| Material | Plastic |
| Halogen free | Yes |
| Material quality | Thermoplastic |
| Mounting/installation | |
| With mounting plate | No |
| Type of fastening | Other |
| Mounting method | Flush-mounted |
| Measurements | |
| Built-in depth | 21.15 mm |
| Device depth | 34.25 mm |
| Min. depth of built-in installation box | 30 mm |
| Device width | 22.5 mm |
| Device height | 45 mm |
| Model/type | |
| Washing machine switch | No |
| Lighting | No |
| Type of lighting | - |
| Number of modules (module system) | 1 |
| Heating switch | No |
| Number of rockers | 1 |
| Label space/information surface | No |
| Assembly arrangement | Basic element with central cover plate |
| Protection | |
| Suitable for degree of protection (IP) | IP40 |
| Colour | |
| RAL-number (similar) | 7021 |
| Colour | Anthracite |
| Options | |
| IFTTT support available | No |
| Push button switch | No |
| Anti-bacterial treatment | No |
| Electrical | |
| Switching current for fluorescent lamps | 10 AX |
| Rated current | 10 A |
| Nominal voltage | 250 V |
| Other | |
| Wiring system | Switch 1-pole |
| Impact strength | - |
| Function lighting | - |
| Connection | |
| Connection type | Other |
| Setting/control | |
| Method of operation | Rocker/button |
| Communication | |
| Compatible with Apple HomeKit | No |
| Monitoring contact | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Package 1 | |
| volume | 36,225 cm3 |
| weight | 15 g |
| length | 4,5 cm |
| width | 3,5 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606489454661 |
| Package 2 | |
| volume | 2685,09 cm3 |
| weight | 384 g |
| length | 18,5 cm |
| width | 17,7 cm |
| qmax | 20 |
| qmin | 20 |
| um | BX |
| gtin | 13606489454668 |
| Package 3 | |
| volume | 36000 cm3 |
| weight | 3,559 kg |
| length | 40 cm |
| width | 30 cm |
| qmax | 160 |
| qmin | 160 |
| um | CT |
| gtin | 43606489454669 |
| Package 4 | |
| weight | 36,972 kg |
| length | 60 cm |
| width | 80 cm |
| qmax | 1280 |
| qmin | 1280 |
| um | PF |
