Descriere
Lampa Ø12, Ip40/Ip65, Rosu, Led Protejat, 48V, Papuci
Documente
Altele
Declaratie de conformitate
Alte surse
Specificatii
| Model/type | |
| With light source | Yes |
| Number of indicator lights | 1 |
| Type of lamp socket | LED |
| Construction type lens | Round |
| With front ring | Yes |
| Type of lens | Flat |
| Colour | |
| Colour lens | Red |
| Colour front ring | Black |
| Electrical | |
| Rated operating voltage Ue | 48 V |
| Voltage type | AC/DC |
| Connection | |
| Type of electric connection | Flat plug-in connection |
| Material | |
| Material front ring | Plastic |
| Measurements | |
| Hole diameter | 12 mm |
| Width opening | - |
| Height opening | - |
| Protection | |
| Degree of protection (IP) | IP40 |
| Degree of protection (NEMA) | - |
| Package 1 | |
| volume | 54,054 cm3 |
| weight | 7 g |
| length | 6,3 cm |
| width | 3,9 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3389110651744 |
| Package 2 | |
| volume | 450 cm3 |
| weight | 74 g |
| length | 15 cm |
| width | 12 cm |
| qmax | 10 |
| qmin | 10 |
| um | BX |
| gtin | 53389110651749 |
| Package 3 | |
| volume | 9000 cm3 |
| weight | 946 g |
| length | 40 cm |
| width | 15 cm |
| qmax | 100 |
| qmin | 100 |
| um | CT |
| gtin | 43389110651742 |
