Descriere
Linergy FT, Comb busbar, 63A, 2 tap-offs, 54mm pitch
Documente
Specificatii
| Measurements | |
| Length | 108 mm |
| Cross section | - |
| Width in number of modular spacings | 54 |
| Module width | 54 mm |
| Colour | |
| Colour | Black |
| Options | |
| Insulated | Yes |
| Connection | |
| Type of electric connection | Fork |
| Electrical | |
| Number of phases | 3 |
| Rated surge voltage | 6 kV |
| Conditioned rated short-circuit current Iq | 11 kA |
| Rated permanent current Iu | 63 A |
| Number of poles | 3 |
| Max. rated operation voltage Ue | 690 V |
| Rated short-time withstand current lcw | - |
| Application | |
| Suitable for devices with auxiliary switch | No |
| Suitable for devices with N-conductor | No |
| Suitable for number of devices | 2 |
| Package 1 | |
| volume | 112 cm3 |
| weight | 40 g |
| length | 14 cm |
| width | 8 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3389110555936 |
| Package 2 | |
| volume | 9000 cm3 |
| weight | 3,36 kg |
| length | 40 cm |
| width | 15 cm |
| qmax | 80 |
| qmin | 80 |
| um | CT |
| gtin | 43389110555934 |
| Package 3 | |
| volume | 360000 cm3 |
| weight | 118,1 kg |
| length | 80 cm |
| width | 60 cm |
| qmax | 2560 |
| qmin | 2560 |
| um | PF |
| gtin | 73389110555935 |
