Descriere
Termostatul Schneider Electric Sedna Design Elements este special conceput pentru uz rezidential, cladiri comerciale, precum si in hoteluri. Acest produs este utilizat in aplicatii de iluminat. Este disponibil ca mecanism cu suport de fixare. Tipul sau de protectie este protectia electronica la scurtcircuit si la suprasarcina automata, avand grija de siguranta dumneavoastra pe cat posibil. Bornele de conectare ale acestui termostat sunt borne cu surub. Directivele indeplinite sunt 2014/30/UE - compatibilitate electromagnetica, 2014/35/UE - directiva de joasa tensiune. Tensiunea nominala de functionare a acestui dispozitiv este de 230 V. Doza de montaj adecvata poate fi incastrata in suprafata peretelui. Dimensiunile sunt (l) 73 mm x (H) 73 mm si (A) 55 mm. Culoarea produsului este alba (RAL 9003) cu un finisaj lucios. Materialul produsului este policarbonat (PC). Clasificarea IP a acestui dispozitiv este IP20. Sedna Design & Elements este o gama accesibila, cu produse care vin intr-o varietate de culori si texturi contemporane. Clientilor le va placea totul la aceste finisaje deosebite, ultra realiste, inclusiv preturile accesibile. Cu Wiser, noua gama Sedna este, de asemenea, o solutie simpla de casa inteligenta care raspunde nevoilor si stilurilor de viata ale clientilor dumneavoastra. A obtinut si certificate CE, EAC. Mai mult, a indeplinit standardul EN 60669-2-5, IEC 60669-2-5.
Documente
Specificatii
| Material | |
| Surface protection | Untreated |
| Surface finishing | Glossy |
| Material | Other |
| Halogen free | Yes |
| Material quality | - |
| Other | |
| Frequency | 50 Hz |
| Impact strength | IK02 |
| Model/type | |
| Type of load | Universal and LED Retrofit |
| Number of modules (module system) | - |
| Assembly arrangement | Basic element with central cover plate |
| Options | |
| Applicable with transmission button | No |
| Applicable with infrared button | No |
| Applicable with movement sensor | No |
| Dimming phase cut-on (leading edge) | Yes |
| Dimming phase cut-off (trailing edge) | Yes |
| IFTTT support available | No |
| Serial dimmer | No |
| Light value memory | Yes |
| Applicable with presence indicator | No |
| Applicable with button | Yes |
| Applicable with time switch/timer | No |
| Protection | |
| Suitable for degree of protection (IP) | IP20 |
| Electrical | |
| Nominal voltage | 230 V |
| Nominal power inductive load | 5 VA |
| Nominal power resistive load | 5 W |
| Control voltage | - |
| Nominal power capacitive load | 5 VA |
| Max. switching power LED | 100 W |
| Colour | |
| RAL-number (similar) | 9003 |
| Transparent | No |
| Colour | White |
| Measurements | |
| Device depth | 55 mm |
| Min. depth of built-in installation box | 27 mm |
| Device width | 73 mm |
| Device height | 73 mm |
| Connection | |
| Core cross section | 1.5 mm² |
| Connection type | Screwed terminal |
| Substation input | Yes |
| Setting/control | |
| App control via Bluetooth | No |
| Method of operation | Turn/push button |
| Mounting/installation | |
| Type of fastening | Mounting with screw |
| Mounting method | Flush-mounted |
| Communication | |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Package 1 | |
| volume | 722 cm3 |
| weight | 134 g |
| length | 9,5 cm |
| width | 9,5 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606481466228 |
| Package 2 | |
| volume | 18000 cm3 |
| weight | 3,626 kg |
| length | 40 cm |
| width | 30 cm |
| qmax | 24 |
| qmin | 24 |
| um | CT |
| gtin | 13606481466225 |
| Package 3 | |
| volume | 720000 cm3 |
| weight | 128,032 kg |
| length | 120 cm |
| width | 80 cm |
| qmax | 768 |
| qmin | 768 |
| um | PF |
