Descriere
Spacial S3D Usa Transparenta Fara Placa De Montaj. H1000Xw600Xd400 Ip66 Ik08 Ral7035.
Documente
Specificatii
| Colour | |
| Colour | Grey |
| RAL-number | 7035 |
| Application | |
| Suitable for 19 inch rack mounting | No |
| Measurements | |
| Width | 248 mm |
| Depth | 103.4 mm |
| Height | 268 mm |
| Energy efficiency/environmental | |
| Noise emission | 56 dB(A) |
| Model/type | |
| Air circulator | Yes |
| With protective cover | Yes |
| Built as slide-in ventilator | Yes |
| EMC-version | No |
| With filter | Yes |
| Roof ventilator | No |
| Number of fans | 1 |
| Electrical | |
| Voltage type | DC |
| Operating voltage AC 50 Hz | - |
| Operating voltage AC 60 Hz | - |
| Operating voltage DC | 48 V |
| Rated power | 11 W |
| Mounting/installation | |
| Mounting method | Snap mounting |
| Suitable for wall built-in | No |
| Protection | |
| Degree of protection (IP) | IP54 |
| Degree of protection (NEMA) | 13 |
| Performance | |
| Volume flow, freeblowing | 262 m³/h |
| Package 1 | |
| volume | 12600 cm3 |
| weight | 1,36 kg |
| length | 28 cm |
| width | 25 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606480151316 |
| Package 2 | |
| volume | 1200000 cm3 |
| weight | 83 kg |
| length | 120 cm |
| width | 100 cm |
| qmax | 50 |
| qmin | 50 |
| um | PF |
