LV HRC FUSE ELEMENT, NH3, IN: 500 A, AM, UN AC: 690V, UN DC: 440 V, FRONT INDICATOR, LIVE GRIP LUGS

Cod produs: 3ND1365

▶

Autentificati-va pentru a vedea pretul.

Producator: Siemens

Set: 1 bucati

4001869020204

Descriere

LV HRC fuse element, NH3, In: 500 A, aM, Un AC: 690 V, Un DC: 440 V, Front indicator, live grip lugs LV HRC fuse link SENTRON for switching device protection in motor circuits. 3ND fuses provide effective protection against short-circuit and are especially suitable for use in motor circuits due to their slow switch-off characteristic. The 3ND LV HRC fuse links are available from 6 A to 630 A in the sizes 000, 00, 0, 1, 2 and 3. SENTRON circuit protection devices - The safe choice. Now made smarter.

Afiseaza mai multa descriere

Documente

Fisa tehnica

Link to Manual
Link to Technical data sheet

Certificat

Link to Certificates

Altele

Link to Sales brochure

Declaratie de conformitate

Link to Declaration RoHS (partly combined Doc with CE-Declaration)
Link to declaration EPD
Link to REACH information
Link to Declaration CE (partly combined Doc with RoHS-Declaration)

Alte surse

Link to SiePortal
Link to Product page

Specificatii

Electrical
Rated voltage AC	690
Power loss at rated current	47
Voltage type	AC
Rated voltage DC	-
Fuse construction type according to IEC 60269	NH3
Rated current	500
Model/type
Type of fuse status indicator	Top fuse status indicator
Other
Utilization category according to IEC 60269	aM
Performance
Rated switching capacity AC	120
Rated switching capacity DC	-
Options
Insulated metal gripping lugs (IMGL)	No
Package 1
weight	1,044
length	0,232
width	0,162
qmax	3
qmin	3
um	PA
gtin	4001869020204
Dimensions of product
Weight	1,044

Afiseaza mai multe specificatii
