Neozed fuse-link
The NEOZED fuse-link is designed for effective protection in electronic installations, providing reliable shutdown during overloads or short circuits.
Technical details:
- D02
- 35 A
- gG
- Un AC: 400 V
- Un DC: 250 V
- With tin-coated contact-caps
- NEOZED fuse link SENTRON 5SE2
Customer benefits:
- Effective protection for personnel, equipment, and plants.
- Reliable shutdown function in case of overload or short circuit.
- Very compact design with low space requirement.
- A wide range of fuse bases and accessories available.
- Increases possible applications in many areas.
Disclaimer: Generated by AI.
Documente
Fisa tehnica
Certificat
Altele
Declaratie de conformitate
Alte surse
Specificatii
| Other | |
| Utilization category according to IEC 60269 | - |
| Electrical | |
| Rated voltage | 400 |
| Rated current | 35 |
| Measurements | |
| Construction size | D02 |
| Model/type | |
| Colour code | Black |
| Package 1 | |
| weight | 0,0136 |
| length | 0,081 |
| width | 0,032 |
| qmax | 10 |
| qmin | 10 |
| um | PA |
| gtin | 4001869005997 |
| Package 2 | |
| volume | 0,026 |
| weight | 16,06 |
| length | 0,44 |
| width | 0,325 |
| qmax | 1200 |
| qmin | 1200 |
| um | CT |
| gtin | 4001869005997 |
| Dimensions of product | |
| Weight | 0,0136 |
