SITOR CYLINDRICAL FUSE LINK, 22X58 MM, 80 A, AR, UN AC: 690V, UN DC: 700 V, DC ACCORDING TO UL
Cod produs: 3NC2280
Alte coduri:
upc: 662643083651
Descriere
SITOR cylindrical fuse link
The SITOR cylindrical fuse link is designed to provide effective protection for electrical installations by ensuring safe shutdown during overload or short-circuit events.
Technical details:
- Dimensions: 22x58 mm
- Rated current: 80 A
- Type: aR
- Un AC: 690 V
- Un DC: 700 V
- DC according to UL
- Model: SENTRON 3NC2
Customer benefits:
- Effective protection of people, equipment, and systems through safe shutdown in case of overload or short-circuits.
- Super-fast switch-off characteristics compared to conventional NH fuses.
- Very good characteristic curve fidelity ensures reliable protection of power semiconductors.
Disclaimer: Generated by AI.
Documente
Fisa tehnica
Certificat
Altele
Declaratie de conformitate
Alte surse
Specificatii
| Electrical | |
| Breaking capacity | 100 |
| Power loss at rated current | 14 |
| Voltage type | AC |
| Release characteristic | Other |
| Rated voltage | 690 |
| Rated current | 80 |
| Measurements | |
| Size | 22x58 mm |
| Model/type | |
| Model | Other |
| Type of fuse status indicator | - |
| Other | |
| Utilization category according to IEC 60269 | aR |
| Rated operating frequency | 45 |
| Package 1 | |
| weight | 0,057 |
| length | 0,115 |
| width | 0,063 |
| qmax | 5 |
| qmin | 5 |
| um | PA |
| gtin | 4011209570153 |
| Dimensions of product | |
| Weight | 0,057 |
