SITOR FUSE LINK, WITH BLADE CONTACTS, NH2, IN: 500 A, GR, UN AC: 690V, UN DC: 440 V, FRONT INDICATOR
Cod produs: 3NE1334-2
Descriere
SITOR fuse link
The SITOR fuse link is designed for effective protection of personnel, equipment, and systems in electrical installations.
Technical details:
- Model: SITOR fuse link SENTRON 3NE1
- Type: NH2
- Rated current (In): 500 A
- Rated voltage AC (Un AC): 690 V
- Rated voltage DC (Un DC): 440 V
- Fuse type: gR
- Contact type: Blade contacts
- Front indicator: Yes
Customer benefits:
- Offers effective protection through safe shutdown in the event of overload or short-circuits.
- Extremely fast switch-off characteristics compared to conventional LV HRC fuses.
- Very good characteristic curve fidelity ensures reliable protection of power semiconductors.
- Part of SENTRON circuit protection devices, providing a safe choice for installations.
Disclaimer: Generated by AI.
Documente
Specificatii
| Electrical | |
| Rated voltage AC | 690 |
| Power loss at rated current | 64 |
| Voltage type | AC/DC |
| Rated voltage DC | 440 |
| Fuse construction type according to IEC 60269 | NH2 |
| Rated current | 500 |
| Model/type | |
| Type of fuse status indicator | Top fuse status indicator |
| Other | |
| Utilization category according to IEC 60269 | gR |
| Performance | |
| Rated switching capacity AC | 100 |
| Rated switching capacity DC | - |
| Options | |
| Insulated metal gripping lugs (IMGL) | No |
| Package 1 | |
| weight | 0,808 |
| length | 0,2 |
| width | 0,27 |
| qmax | 3 |
| qmin | 3 |
| um | PA |
| gtin | 4011209568136 |
| Dimensions of product | |
| Weight | 0,808 |
