SITOR FUSE LINK, WITH BOLT-ON LINKS, NH00, IN: 100 A, GR, UN AC: 690V, UN DC: 440 V, FRONT INDICATOR
Cod produs: 3NE8021-3MK
Descriere
SITOR fuse link, with Bolt-on links, NH00, In: 100 A, gR, Un AC: 690 V, Un DC: 440 V, front indicator SITOR fuse link SENTRON 3NE8 for SITOR semiconductor fuses. As an important component of the SENTRON protection components for electrical installations, the SITOR fuse system offers effective protection of personnel, equipment and systems through safe shutdown in the event of overload or short-circuits. Due to their extremely fast switch-off characteristics, compared to conventional LV HRC fuses, as well as their very good characteristic curve fidelity, power semiconductors are also reliably protected. SENTRON circuit protection devices - A safe choice.
Documente
Specificatii
| Electrical | |
| Rated voltage DC | 440 |
| Power loss at rated current | 29 |
| Rated voltage AC | 690 |
| Fuse construction type according to IEC 60269 | NH00 |
| Voltage type | AC/DC |
| Rated current | 100 |
| Model/type | |
| Type of fuse status indicator | Top fuse status indicator |
| Options | |
| Insulated metal gripping lugs (IMGL) | No |
| Performance | |
| Rated switching capacity DC | 50 |
| Rated switching capacity AC | 100 |
| Other | |
| Utilization category according to IEC 60269 | gR |
| Package 1 | |
| weight | 0,205 |
| length | 0,095 |
| width | 0,105 |
| qmax | 3 |
| qmin | 3 |
| um | PA |
| gtin | 4001869497723 |
| Dimensions of product | |
| Weight | 0,205 |
